Whitener

Whitener

ABRASIVE STONE POLISHER

Whitener is otherwise known an abrasive polisher. This is a technique used to remove a layer of bran from rice by polishing using rough stones. The rice is gently passed through the abrasion chamber between specific silicon carbide stones and, by this process, the brown rice turns white. The removed bran is collected by the attached external suction blower.

Supported Commodities

Rice

Rice

Result

Input

Brown Rice

Brown Rice

Output

Semi Polished Rice

Semi Polished Rice

Rice Bran

Rice Bran

Models & Technical Specification

Model WTR03 WTR04 WTR06 WTR08 WTR12
Capacity (TPH) 2.5 to 3 3 to 4 5 to 6 7 to 8 8.0 / 10.0 / 12.0
Motor Power (HP) 30 40 50 60 75/100/120
Motor RPM 1440 1440 1440 1440 1440
Abrasive Stone count 6 6 6 6 9
Total Screens 3 3 3 3 4
Weight (Kg) 900 950 1600 1700 2700
Dimension LxBxH (Ft, In) 4'8" x 2'0" x 5'3" 4'8" x 2'0" x 5'3" 5'4" x 2'7" x 5'6" 5'4" x 2'7" x 5'6" 6'2" x 3'3" x 6'2"

*Note : This content is shown for Paddy.

Advanced Features

Silicon Carbide Stones
Silicon Carbide Stones

Green silicon carbide and Black Silicon carbide are used. Stones are used based on type of processed rice

Sieves
Sieves

Hardened Steel is used for longer self-life, and multiple range of perforation for multiple combinations.

Top-to-bottom Flow
Top-to-bottom Flow

Machine is designed to feed rice from top bran is removed in the middle and collected at the bottom

Magnehelic Gauge
Magnehelic Gauge

Maintaining proper chamber pressure is one of the key feature to be ensured at the time of machine startup.

Special Metal Knife
Special Metal Knife

Blade/ Knife made with EN8 material for extended self life and uniform whiteness.

Rigid and low maintenance
Rigid and low maintenance

Quick and easy replaceable screen with sieves. minimum wear and tear parts.

Product Video
